a k autto electrical an ISO 9001:2008 certified company is one of the leading manufacturers of Eco-friendly Battery operated Electric Golf Cars. We have a strong technical and skilled work force, who have taken a giant leap to develop and nurture environment friendly commuting solution by introducting MARVELLA.
Models Available:
6 Seater
8 Seater
Quality Features:-
Imported LED Head Light
Fog Lamp
Heavy Duty Bumper
Eye Light
Alloy Wheel with Disc Brake
ERW Material Chassis for high strength with powder coating to prevent rust
High Quality Fiber Glass Body
Comfortable Cusion Seats
304 Grade Stainless Steel round rod and supporting rod provide high strength
Glass Steel Roof, High Temperature Bearing, Corrosion & Rust Free, Beautiful Appearance with strong texture
Toughened Glass
High Grade Leather Dashboard
Dikki
AVAILABLE IN WIDE RANGE OF COLORS
Key Features
DETAIL
6 SEATER
8 SEATER
Controller
Controller 48 V - 400 AMP.
Controller 48 V - 400 AMP.
Motor Power
48 V 4 KW DC Motor
48 V 4 KW DC Motor
Battery
6 V 225 AH Battery 8 Pcs.
6 V 225 AH Battery 8 Pcs.
Charger
High Frequency Onboard Charger, Output 48V/22A.
High Frequency Onboard Charger, Output 48V/22A.
Performance
DETAIL
6 SEATER
8 SEATER
Passenger Capacity
6 Persons (4+2 Seater)
8 Persons (6+2 Seater)
Range (Loaded) (Km)*
Up to 70 Km
Up to 70 Km
Max Speed (Km/h)
Up to 25 Km/h
Up to 25 Km/h
Min. Turning Radius (m)
4.5 m
4.5 m
Max. Climbing Ability (m)
Up to 10%
Up to 10%
Max. Movement after brake at speed of 20 Km/h
≤ 1.5 m
≤ 1.5 m
Max. Loading Weight (Kg)
420 Kgs
560 Kgs
Charging Time (hour)
8
8
Steering & Suspension
DETAIL
6 SEATER
8 SEATER
Steering System
Single-Stage Rack and Pinion Steering System
Single-Stage Rack and Pinion Steering System
Brake System
4 Wheel Hydraulic Front Disc, Rear Drum Brake with parking brake
4 Wheel Hydraulic Front Disc, Rear Drum Brake with parking brake
Accelerator
Resistance Type, Step Less Speed Change
Resistance Type, Step Less Speed Change
Front Suspension
Independent Suspension with double arm
Independent Suspension with double arm
Rear Suspension
Taper Leaf Spring with hydraulic cylinder shock absorber
Taper Leaf Spring with hydraulic cylinder shock absorber
Driving Mode
Rear Axle Two Stage Deceleration, Motor Direct Driving
Rear Axle Two Stage Deceleration, Motor Direct Driving
Rear Axle
Aluminium Differential Cage, Integrated, 10.25:1 Gear Ratio
Aluminium Differential Cage, Integrated, 10.25:1 Gear Ratio
Wheel & Tyre
Alloy Wheel 175/65-15
Alloy Wheel 175/65-15
Dimension
DETAIL
6 SEATER
8 SEATER
Overall Dimension (mm)
4000 x 1370 x 1970 (L x W x H)mm
4860 x 1370 x 1970 (L x W x H)mm
Min. Ground Clearance (mm)
220
220
Wheel Base (mm)
2700
3500
Front Wheel Tread(mm)
1105
1105
Rear Wheel Tread(mm)
1150
1150
Body Frame
DETAIL
6 SEATER
8 SEATER
Frame & Chassis
ERW2 Welded, Steel Frame work with rust proof coating painting.
ERW2 Welded, Steel Frame work with rust proof coating painting.
Body & Roof
High Impact Fiber Glass
High Impact Fiber Glass
Windshield
Toughened Laminated Safety Glass
Toughened Laminated Safety Glass
Roof Support
Stainless Steel Frame
Stainless Steel Frame
Cushion
Reborn Sponge with Artificial Leather and wooden bottom.
Reborn Sponge with Artificial Leather and wooden bottom.
Backrest
Reborn Sponge with Artificial Leather.
Reborn Sponge with Artificial Leather.
Armrest
Part of Body.
Part of Body.
Floor Mat
Skip Proof Rubber.
Skip Proof Rubber.
Dashroof
Colored Leather with F/R Switch, Battery Power Indicator, Ignition Key on it.
Colored Leather with F/R Switch, Battery Power Indicator, Ignition Key on it.
Electric Systems
DETAIL
6 SEATER
8 SEATER
Lights
12 V LED Head light front turning, Fog, Tail Light (includes brake light & turning light
12 V LED Head light front turning, Fog, Tail Light (includes brake light & turning light
Horn
Electric Horn 12V
Electric Horn 12V
DC to DC Converter
48 V to 12 V 22 Amps.
48 V to 12 V 22 Amps.
Wiper & Wiper Motor
Electric 12 V
Electric 12 V
Digital Meter
Including Speedometer, Mileage, Various indicators including: Headlight, Turning Light, Parking, Emergency Light & Reverse.
Including Speedometer, Mileage, Various indicators including: Headlight, Turning Light, Parking, Emergency Light & Reverse.
